Capcom DMD Display Driver Power Supply Board – A00155-05

Description

Capcom DMD Display Driver Power Supply Board – A00155-05

Plug and play direct replacement DMD PSU PCB

Replaces Capcom part number – A00155 Rev-05

This board has been designed 1:1 to the original V2 board, using the original NOS XF00103 flyback transformer, and genuine LT1271 voltage regulator. All capacitors are long life Nichicon/Rubycon capacitors. Pin headers have been upgraded to Molex locking headers, and top and bottom ground plains have been added for higher ground efficiency.

– Designed 1:1 to the original board
– High quality components (We only use genuine components from reputable companies,(ST, Onsemi, Molex, Nichicon, TE Connectivity, Vishay, Yageo etc)
– Supports every single game as the original
– 12 Months local warranty
– Designed and assembled in Australia

Game Compatibility:

Airborne
Big Bang Bar
Breakshot
KingPin
Pinball Magic

References – A00155, A00155-05
